OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
FAILURE TO CORRECTLY MAINTAIN AND CHECK THIS MACHINE COULD RESULT IN
DEATH OR SERIOUS INJURIES.
THIS MACHINE MUST NOT BE USED IF IT IS NOT IN PERFECT WORKING
CONDITION.
Section 3. PREPARATION AND INSPECTION
Before use, careful inspection and operating check are recommended to ensure that the
machine is in perfect working order.
Do not use the machine if it is damaged or has an operating defect.
Depending on national or local regulations, the machine must be submitted to periodic
verifications and testing.
3.1 INSPECTION BEFORE START UP
1- Make sure that there are no oil or fuel leaks. Check the machine's general cleanliness (slippy
substances on the platform floor).
2- Inspect the machine's structure to detect any damaged parts, cracked welds or any other
anomaly.
3- Check the presence and legibility of the safety stickers. Clean or replace any illegible
stickers.
4- Check that there is a copy of the operator and safety manual in the working platform's
document holder.
5- Carry out the inspection tour described below.
6- Carry out the operating checks described below.
3.2 INSPECTION TOUR
Check each element in the list below in order. For each element, in addition to the criteria
mentioned, check that no parts are loose or missing, that the elements are correctly attached
and that they have no leaks or visible damage.
1- - Diesel engine and accessories: Oil level, cooling fluid level – Hydraulic pumps.
2- Electric cables – Cable run and tightening of the battery connections.
3- Lock of the engine support turntable: Presence of the lock pin on the latch.
4- Oscillating axle - Oscillating axle cylinders.
5- Steering cylinder - Steering bar.
6- Front wheel motors - Wheel pivot pins: No screws missing - Screws correctly tightened.
7- Wheels: Tyres in good condition – No wheel nuts missing – Wheels correctly tightened
