6.1. EMERGENCY CONTROLS
The emergency controls must only be used by personnel with detailed knowledge of the
machine's operating characteristics and the ground control function.
If the platform is jammed or stuck in a structure or equipment at height, stop using the machine
immediately. Use other equipment to rescue the platform's occupants. Stabilise the machine
before you try to release it. Make sure you do not control any movements that might result in the
machine tipping over.
6.1.1 EMERGENCY STOP
Each control station has an emergency stop button that stops the machine's movements and
cuts the diesel engine when it is pushed in.
6.1.2 GROUND CONTROL STATION
The priority ground control station is used to raise or lower the platform in the event of an
emergency, when the operator in the work platform is unable to operate the machine.
1- Set the control station selector to "ground control station ".
2- Start the diesel engine.
3- Check that there are no obstacles at height that might interfere when the platform is
moved.
4- Activate the appropriate movement controls to raise or lower the platform.
6.1.3 AUXILIARY HYDRAULIC GROUP
In the event of a breakdown on the diesel engine, an auxiliary group is used to power the
machine's hydraulic circuit to return the platform to its low position. The hydraulic group is
powered by the diesel engine's start-up battery. It may be used from the ground control
station or from the work platform's control station. The auxiliary hydraulic group may only be
used when the diesel engine is stopped.
 From the ground control station
1- Activate and hold down the enable button. When the diesel engine is stopped, the
auxiliary hydraulic group can run using the enable button.
2- Use the controls to take the platform back to its low position.
 Depuis le poste de commande de la plate-forme de travail
1- Press the validation pedal.
2- Toggle and hold the Start / Auxiliary Group button downwards.
3- Use the controls to take the platform back to its low position.
6.2. EMERGENCY TOWING
In case of engine failure or machine malfunction, it is possible, after releasing the brakes, to tow
the machine.
