OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
18
2.7. OPERATING LIMITATIONS
Model
Zebra 12
Max. floor height
10.20 m
Max. working height
12.20 m
Maximum number of occupants in the work
platform
2
Maximum load on the platform (distributed)
230kg
Maximum wind speed
12.5m/s (45km/h)
Maximum manual force
400 Newton
Max. Tilt
Transversal
4 degrees
Longitudinal
4 degrees
Max slope (see Note)
40%
Operating temperature
-20 … +60°C
-NOTE-
Do not run the diesel engine for over 10 minutes with a tilt or slope over 35%.
2.8. TOWING, LIFTING, TRANSPORT
 Do not tow, lift or transport the machine with people or material in the work platform.
 Lower the platform completely before towing, lifting or transporting the machine.
 The machine must only be towed or lifted in the event of an emergency, a malfunction, a fault
or for loading/unloading. See 6.2 – Emergency towing.
 Check the capacity of the equipment used to tow, lift or transport the machine.
2.9. MAINTENANCE
 To guarantee the machine's safety, a maintenance and operating verification programme
must be established by a qualified person taking into account the information provided in this
manual and in the maintenance manual.
 Before performing any maintenance or repair operations, cut the power to the control
stations.
 Never work under the work platform or on the lifting structure without it being supported and
immobilised by appropriate slinging.
 Disconnect the battery when working on the electrical circuit or when welding.
 Do not smoke, introduce flames, sparks near the battery.
 Do not place any metal tools or objects on the battery terminals.
 The acid contained in the battery is highly corrosive. Make sure that it does not come into
contact with skin, eyes or clothing. Wear appropriate protective equipment when maintaining
the battery.
 Only charge the battery in well-ventilated premises.
