OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
CHECK THE CAPACITY OF THE
LIFTING EQUIPMENT AND
ACCESSORIES BEFORE RAISING THE
MACHINE.
CHECK THAT THE PIVOTING MOTOR
SUPPORT IS CORRECTLY LOCKED.
WHEN HANDLING THE MACHINE,
THERE MUST BE NO PEOPLE OR
MATERIAL ON THE WORK PLATFORM.
4.6. HANDLING – STOWAGE FOR TRANSPORT
4.6.1 HANDLING
The machine may be handled using a crane
or similar equipment using the lifting/stowage
rings on the chassis. You must then use
adapted lifting accessories to avoid
damaging the machine.
For the operation, the machine must be
placed in parking-storage position as
described in Section 4.5.
4.6.2 STOWAGE FOR TRANSPORT
During transport :
The machine must be solidly secured to the vehicle’s deck as shown below. To tie down
the chassis, use chains or slings rather than textile straps. To prevent vibrations during
transport, bring the work platform to contact the vehicle’s deck using the platform
levelling control from the ground control station (place a protection between the deck and
the work platform to prevent damages). Strap the platform as shown (do not strap too
tight to prevent damage to the platform).
The wheels can also be chocked.
Remove all the elements not secured to the machine.
