OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
36
DANGER
ONLY RAISE THE PLATFORM IF THE
MACHINE IS ON EVEN, FIRM,
HORIZONTAL AND FLAT GROUND.
IF THE TILT ALARM IS TRIGGERED,
RETRACT THE TELESCOPE AND
RETURN THE PLATFORM TO ITS LOW
POSITION.
DO NOT USE THE GROUND STATION
CONTROLS WHEN THERE ARE
OCCUPANTS ON THE PLATFORM
EXCEPT IN AN EMERGENCY. REFER
TO THE SAFETY INSTRUCTIONS IN
SECTION 2 IN THIS MANUAL.
 Steering
The machine can be steered using the toggle switch on top of the joystick.
Activate the enable pedal and with the thumb, toggle the switch to the right to steer the
wheels to the right, or to the left to steer the wheels to the left.
The wheels remain steered when the switch is released: toggle the switch in the opposite
direction to straighten the wheels.
4.4. LIFTING STRUCTURE
4.4.1 ENGINE SPEED
A speed range may be selected for the
structure movements with the engine speed
selector. See Section 4.2.2 – Engine rate.
The engine high speed for the structure
movements must only be used if the machine
is being used in an area free of any
obstacles. See Section 2.3 – Crushing and
collision risk.
For approach movements, we recommend
performing the movements with the engine
slowed down.
4.4.2 ELEVATION
 From the ground control station
1- Activate and hold down the enable button. The enable button must be activated before a
movement is controlled.
2- Tilt the arm 1, 2 or 3 control switch upwards to raise the corresponding arm. Tilt the arm
1, 2 or 3 control switch downwards to lower the corresponding arm.
3- To stop the movement, release the control switch or the enable button.
 From the work platform control station
1- Select the engine speed required.
2- Activate the enable pedal.
3- Within 5 seconds, tilt the arm 1, 2 or 3 control lever/joystick upwards to raise the
corresponding arm or downwards to lower the corresponding arm.
The arm 2 movement speed is proportional to the joystick displacement.
The arm 1 and 3 movement speed may be adjusted using the speed adjustment gauge.
4- To stop the movement, place the lever/joystick into neutral to reduce the speed and
release the enable pedal.
