OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
37
DANGER
WHEN THE PLATFORM IS ELEVATED,
ONLY USE THIS CONTROL TO MAKE A
SLIGHT LEVEL CORRECTION.
INAPPROPRIATE USE OF THIS
CONTROL MAY CAUSE OBJECTS OR
OCCUPANTS ON THE WORK
PLATFORM TO FALL OFF.
4.4.3 TELESCOPE
 From the ground control station
1- Tilt and hold the enable button downwards.
2- Tilt the telescope control switch upwards to extend the telescope. Tilt the control switch
downwards to retract the telescope.
3- To stop the movement, release the control switch or the enable button.
 From the work platform control station
1- Select the engine speed required.
2- Activate the enable pedal.
3- Within 5 seconds, tilt the telescope control switch backwards to extend the telescope and
backwards to retract the telescope.
The telescope movement speed may be adjusted using the speed adjustment gauge.
4- To stop the movement, put the switch into neutral to reduce the speed and release the
enable pedal.
4.4.4 LEVELLING THE PLATFORM
This command is used to adjust the platform's horizontal level when driving on a slope.
 From the ground control station
1- Activate and hold down the enable
button.
2- Tilt the levelling control switchr upwards
or downwards to correct the work
platform's horizontal level in the
corresponding direction.
3- To stop the movement, release the
control switch or the enable button.
 From the work platform control station
1- Activate the enable pedal.
2- Within 5 seconds, tilt the levelling control switch upwards or downwards to correct the
work platform's horizontal level in the corresponding direction.
3- To stop the movement, release the control switch or the enable button.
-NOTE-
Disabling this function when the working platform is in high position may be configured
in the system: See §8.3.1 - Settings
