OPERATOR’S AND SAFETY MANUAL
1NO0039UK-00
Zebra 12
53
8.2.1 ENGINE / TRANSMISSION (F1)
1- Entry parameters – Drive / steering Joystick.
2- Variable flow pump control value.
3- Parameters – Steering movement.
4- Light – Parking brake : the icon turns grey when the brake is deactivated.
The arrows light up when the corresponding movement is controlled
Proportional valve control setpoint
Steering Hydraulic circuit pressure
The arrows light up when the corresponding movement is controlled
Joystick set point value – Drive movement
(8)
(1)
(6)
(7)
(5)
(10)
(9)
(2)
(11)
(12)
(3)
(4)
