PROGRAMMING MENU
2H Stop Mode Coast To Stop
2I Stop Time 0m:00s
2J Adaptive Stop Profile Constant Deceleration
2K Adaptive Control Gain 75%
2L
Brake Torque
20%
2M
Brake Time
0m:01s
3
Auto-Start/Stop
3A Auto-Start Type Off
3B Auto-Start Time 00h:01m
3C Auto-Stop Type Off
3D Auto-Stop Time 00h:01m
4
Protection Settings
4A Excess Start Time 0m:20s
4B Excess Start Time-2 0m:20s
4C Undercurrent 20%
4D Undercurrent Delay 0m:05s
4E Instantaneous Overcurrent 400%
4F Instantaneous Overcurrent Delay 0m:00s
4G Phase Sequence Any Sequence
4H Current Imbalance 30%
4I Current Imbalance Delay 0m:03s
4J Frequency Check Start/Run
4K Frequency Variation ± 5Hz
4L Frequency Delay 0m:01s
4M Restart Delay 10s
4N Motor Temperature Check Do Not Check
4O Ground Fault Level 100 mA
4P Ground Fault Delay 0m:03s
4Q
Reserved
-
4R
Reserved
-
4S
Reserved
-
4T
Reserved
-
5
Auto-Reset Trips
5A Auto-Reset Action Do Not Auto-Reset
5B Maximum Resets 1
5C Reset Delay Groups A&B 00m:05s
5D Reset Delay Group C 05 m
6
Inputs
6A Input A Function Motor Set Select
6B Input A Name Input Trip
6C Input A Trip Always Active
6D Input A Trip Delay 0m:00s
6E Input A Initial Delay 0m:00s
6F Input B Function Input Trip (N/O)
6G Input B Name Input Trip
6H Input B Trip Always Active
6I Input B Trip Delay 0m:00s
6J Input B Initial Delay 00m:00s
6K Input C Function Off
6L Input D Function Off
