INSTALLATION
16 | MVE User Manual (710-17074-00G)
MVE-0070~0540, V06
NOTE
For these models, terminations can be made at either end of the input and output busbars.
19213.A
A
AC
C
B B
B B B B
2/T1 4/T2 6/T3
1/L1 3/L2 5/L3
D
E
F
A
mm (inch)
B
mm (inch)
C
mm (inch)
D
mm (inch)
E
mm (inch)
F
mm (inch)
MVE-0070-V06 ~ MVE-0540-V06
60
(2.4)
63
(2.5)
126
(5.0)
626
(24.6)
336
(13.2)
406
(16.0)
MVE-0600-1700, V02~V06
A C
B
D
B
AC
BB
E
F
17206.A
L1
L2 L3
T1 T2 T3
A
mm (inch)
B
mm (inch)
C
mm (inch)
D
mm (inch)
E
mm (inch)
F
mm (inch)
MVE-0600-V02 ~ MVE-1700-V02
77
(3.1)
320
(12.6)
242
(9.5)
1280
(50.4)
620
(24.4)
640
(25.2)
MVE-0600-V03 ~ MVE-1700-V03
MVE-0600-V04 ~ MVE-1700-V04
MVE-0600-V06 ~ MVE-1700-V06
