APPENDIX
MVE User Manual (710-17074-00G) | 73
11. Appendix
11.1 Parameter Defaults
If you require assistance from your supplier or a service technician, please note all parameter settings in the table below.
1
Primary Motor Settings
User Set 1
User Set 2
Default Value
1A Motor Full Load Current 100 A
1B
Locked Rotor Time
00m:10s
1C Locked Rotor Current 600% FLC
1D Motor Service Factor 105%
2
Start/Stop Modes-1
2A
Start Mode
Constant Current
2B Start Ramp Time 00m:01s
2C Initial Current 400% FLC
2D
Current Limit
400% FLC
2E Reserved
2F Kickstart Time 0 ms
2G Kickstart Level 500% FLC
2H
Stop Mode
Coast To Stop
2I Stop Time 00m:00s
3
Auto-Start/Stop
3A
Reserved
3B
Reserved
3C Auto-Stop Type Off
3D Auto-Stop Time 00h:01m
4
Protection Settings
4A Excess Start Time 00m:20s
4B Excess Start Time-2 00m:20s
4C Undercurrent 20% FLC
4D
Undercurrent Delay
00m:05s
4E Instantaneous Overcurrent 400% FLC
4F Instantaneous Overcurrent Delay 00m:00s
4G
Phase Sequence
Positive Only
4H
Current Imbalance
30%
4I Current Imbalance Delay 00m:05s
4J Frequency Check Run
4K
Frequency Variation
±5 Hz
4L Frequency Delay 00m:05s
4M Restart Delay 30m:00s
4N Motor Temperature Check Do Not Check
4O
Ground Fault Level
1 A
4P Ground Fault Delay 00m:03s
4Q Undervoltage 100 V
4R
Undervoltage Delay
00m:05s
4S
Overvoltage
7200 V
4T Overvoltage Delay 00m:05s
4U Instantaneous Overcurrent S2 4400 A
4V
Instantaneous Overcurrent Delay S2
10 ms
