APPENDIX
74 | MVE User Manual (710-17074-00G)
5
Auto-Reset Trips ( Reserved )
5A
Reserved
6
Inputs
6A Input A Function Input Trip (N/O)
6B Input A Name Input Trip
6C
Input A Trip
Always Active
6D Input A Trip Delay 00m:00s
6E Input A Initial Delay 00m:00s
6F Input B Function Input Trip (N/O)
6G
Input B Name
Input Trip
6H Input B Trip Always Active
6I Input B Trip Delay 00m:00s
6J
Input B Initial Delay
00m:00s
6K
Reserved
6L Reserved
6M Remote Reset Logic Normally Closed (N/C)
6N
Reserved
6O Reserved
6P Reserved
6Q Local/Remote LCL/RMT Anytime
6R
Comms in Remote
Enable Control in RMT
7
Outputs
7A Relay A Function Main Contactor
7B
Relay A On Delay
00m:00s
7C
Relay A Off Delay
00m:00s
7D Relay B Function Run
7E Relay B On Delay 00m:00s
7F
Relay B Off Delay
00m:00s
7G Relay C Function Trip
7H Relay C On Delay 00m:00s
7I Relay C Off Delay 00m:00s
7J
Reserved
7K Reserved
7L Reserved
7M
Low Current Flag
50% FLC
7N
High Current Flag
100% FLC
7O Motor Temperature Flag 80%
7P Analog Output A Current (% FLC)
7Q
Analog A Scale
4-20 mA
7R Analog A Maximum Adjustment 100%
7S Analog A Minimum Adjustment 0%
7T Reserved
7U
Reserved
7V Reserved
7W Reserved
