APPENDIX
MVE User Manual (710-17074-00G) | 75
8
Display
8A
Language
English
8B
F1 Button Action
Setup Auto-Start/Stop
8C F2 Button Action None
8D Display A or kW Current
8E
User Screen - Top Left
Starter State
8F User Screen - Top Right Blank
8G User Screen - Bottom Left kWh
8H User Screen - Bottom Right Hours Run
8I
Graph Data
Current (% FLC)
8J Graph Timebase 10 seconds
8K Graph Maximum Adjustment 400%
8L
Graph Minimum Adjustment
0%
8M
Mains Reference Voltage
400 V
9
Motor Data-2
9A Reserved
9B
Motor FLC-2
100 A
9C Reserved
9D Reserved
9E Reserved
10
Start/Stop Modes-2
10A Start Mode-2 Constant Current
10B Start Ramp-2 00m:01s
10C
Initial Current-2
400% FLC
10D
Current Limit-2
400% FLC
10E Reserved
10F Kickstart Time-2 0 ms
10G
Kickstart Level-2
500% FLC
10H Stop Mode-2 Coast To Stop
10I Stop Time-2 00m:00s
11
RTD/PT100 ( Reserved )
11A
Reserved
12
Slip-Ring Motors
12A Motor Data-1 Ramp Single Ramp
12B
Motor Data-2 Ramp
Single Ramp
12C
Changeover Time
150 ms
12D Slip Ring Retard 50%
15
Advanced
15A
Access Code
0000
15B Adjustment Lock Read & Write
15C Emergency Run Disable
