CONTROLLER
MVE User Manual (710-17074-00G) | 31
Operating Feedback
NOTE
Screens shown here are with the default settings.
• Starter Status
The starter status screen shows details of the starter's operating status, including motor current, power and temperature.
0A
Ready
M1 000% 000.0kW
• Programmable screen
The MVE's user-programmable screen can be configured to show the most important information for the particular application.
Use parameters 8E to 8H to select which information to display.
0A
Ready
00000 kWh 00000hrs
• Motor Temperature
The temperature screen shows which motor data set is in use, and the temperature of the motor as a percentage of total thermal
capacity.
0A
Primary Motor Set
M1 000% M2 000%
NOTE
M2 xxx% temperature is not applicable to this product.
• Current monitoring screen
The current screen shows real-time line current on each phase.
0A
Phase Currents (Gnd Crnt XX.XA)
000.0A 000.0A 000.0A
• Motor Power
The motor power screen shows motor power (kW, HP and kVA) and power factor.
0A
000.0kW 0000HP
0000kVA -. - - pf
• Voltage
The voltage screen shows real-time line voltage across each phase.
0A
Line Voltages
00000 00000 00000
• Last Start Information
The last start information screen shows details of the most recent start:
• start duration (seconds)
• maximum start current drawn (as a percentage of motor full load current)
• calculated rise in motor temperature
0A
Last start 000 s
000 % FLC ∆ Temp 0%
