AuCom MVE series - Page 45

CONTROLLER
44 | MVE User Manual (710-17074-00G)
4P Ground Fault Delay
4Q Undervoltage
4R Undervoltage Delay
4S Overvoltage
4T Overvoltage Delay
4U Instantaneous Overcurrent S2
4V Instantaneous Overcurrent Delay S2
5
Auto-Reset Trips ( Reserved )
5A Reserved
6
Inputs
6A Input A Function
6B Input A Name
6C Input A Trip
6D Input A Trip Delay
6E Input A Initial Delay
6F Input B Function
6G Input B Name
6H Input B Trip
6I Input B Trip Delay
6J
Input B Initial Delay
6K
Reserved
6L
Reserved
6M
Remote Reset Logic
6N
Reserved
6O
Reserved
6P
Reserved
6Q
Local/Remote
6R
Comms in Remote
7
Outputs
7A
Relay A Function
7B
Relay A On Delay
7C
Relay A Off Delay
7D
Relay B Function
7E
Relay B On Delay
7F
Relay B Off Delay
7G
Relay C Function
7H
Relay C On Delay
7I Relay C Off Delay
7J Reserved
7K Reserved
7L Reserved
7M Low Current Flag
7N High Current Flag
7O Motor Temperature Flag
7P Analog Output A
7Q Analog A Scale
7R Analog A Maximum Adjustment
7S Analog A Minimum Adjustment
