Parameter 7R Analog A Maximum Adjustment
Range:
0% - 600%
Default:
100%
Description:
Calibrates the upper limit of the analog output to match the signal measured on an external current
measuring device.
Parameter 7S
Analog A Minimum Adjustment
Range:
0% - 600%
Default:
0%
Description:
Calibrates the lower limit of the analog output to match the signal measured on an external current
measuring device.
7T~7W – Reserved
These parameters are reserved for future use.
8 Display
These parameters allow the controller to be tailored to individual users' requirements.
8A – Language
Options:
English (default) Português
Chinese Français
Español Italiano
Deutsch Russian
Description:
Selects which language the controller will use to display messages and feedback.
8B, 8C – F1 and F2 Button Action
Options:
None
Setup Auto-Start/Stop
Description:
Selects the function of the
F1
and
F2
buttons on the controller.
• 8B F1 Button Action
Default:
Setup Auto-Start/Stop
• 8C
F2 Button Action
Default:
None
8D – Display A or kW
Options:
Current (default)
Motor kW
Description:
Selects whether the MVE will display current (amperes) or motor kilowatts on the main monitoring screen.
8E, 8F, 8G, 8H – User-Programmable Screen
Options:
Blank
Displays no data in the selected area, allowing long messages to be
shown without overlapping.
Starter State
The starter's operating state (starting, running, stopping or tripped).
Only available for top left and bottom left positions on the screen.
Motor Current The average current measured on three phases.
Motor pf
The motor's power factor, measured by the soft starter.
Mains Frequency The average frequency measured on three phases.
Motor kW The motor's running power in kilowatts.
Motor HP The motor's running power in horsepower.
Motor Temp
The motor's temperature, calculated by the thermal model.
kWh
The number of kilowatt hours the motor has run via the soft starter.
Hours Run The number of hours the motor has run via the soft starter.
Analog Input n/a
Mains Voltage
The average voltage measured on three phases.
Description:
Selects which information will be displayed on the programmable monitoring screen.
• 8E User Screen - Top Left
Default:
Starter State
• 8F
User Screen - Top Right
Default:
Blank
• 8G User Screen - Bottom Left
Default:
kWh
• 8H
User Screen - Bottom Right
Default:
Hours Run
