4.2.4 Temperature Increase Downstream
from Evaporator, Determining Malfunc‐
tion
The required cooling output is reached during the cooling output
test however, the air leaving the evaporator is too warm. Refer to
⇒ “4.2.2 Cooling Output, Checking“, page 81
– Clamp off both coolant hoses from engine to heater core of A/C unit e.g. using Hose Clamps, Up to 40
mm -3093- . Refer to ⇒ “5.14 Heater Core“, page 144 .
– Repeat cooling performance test. Refer to ⇒ “4.2 A/C Unit, Checking Cooling Output“, page 79 .
– Read the measured values from the left footwell vent temperature sensor -G261- , from the right footwell
vent temperature sensor -G262- and from the evaporator vent temperature sensor -G263- using -
VAS5051B- under "Guided Fault Finding."
• The measured values from left footwell vent temperature sensor and right footwell vent temperature
sensor differ by less than 3 °C from the measured value from the evaporator vent temperature sensor.
Refer to -VAS5051B- under "Guided Fault Finding."
↓
yes
↓
↓
no
↓
–Remove Hose Clamps, Up to 40 mm -3093-
from both coolant hoses.
↓
– Check the sensor at which the measure value deviates
for correct installation and its electrical connections for
contact resistance using -VAS5051B- in "Guided Fault
Finding" and ⇒ Wiring diagrams, Troubleshooting &
Component locations.
–Check activation and function of Left Temper‐
ature Door Motor -V158- and of Right Tem‐
perature Door Motor -V159- . Refer to
⇒ “4.2.4 Temperature Increase Downstream
from Evaporator, Determining Malfunction“,
page 88 and
⇒ “4.6 Heating Performance Of A/C System,
Checking“, page 93 .
↓
– Eliminate the cause of incorrect measured value, re‐
place defective sender.
• If the actuation and the function of the left temperature door motor -V158- and the right temperature door
motor -V159- OK.
↓
yes
↓
no
↓
–Check operation of temperature door for side
of air distribution housing responsible for tem‐
perature increase. Refer to
⇒ “2.1 Air Routing and Distribution in Passen‐
ger Compartment“, page 44 .
–Replace air distribution housing if necessary.
Refer to ⇒ “5.3 A/C Unit“, page 108 .
↓
–Repeat cooling performance test. Refer to
⇒ “4.2 A/C Unit, Checking Cooling Output“,
page 79 .
–Repair cause of malfunction. Refer to -VAS5051B- in
"Guided Fault Finding" and ⇒ Wiring diagrams, Trou‐
bleshooting & Component locations.
↓
–Repeat cooling performance test. Refer to
⇒ “4.2 A/C Unit, Checking Cooling Output“, page 79 .
4.2.5 Ice Formation on Evaporator, Localizing
Malfunction
♦ A/C Compressor Regulator Valve -N280- is activated by Cli‐
matronic control module -J255- so that temperature of air
