The selected filter for each measurement function is remembered, so
that next time you use that function the same filter will be selected.
Printer support is provided, allowing printout of high-resolution graphs,
fast screen dumps, numerical data from sweeps or self-test, and
printout of bargraph displays.
Signals within the audible range can be monitored using the built-in
loudspeaker or with user-supplied headphones. An external volume
control is provided.
Up to 30 complete panel setups can be stored in internal memory so
that common test setups can be easily recalled. This memory persists
even when the unit is unplugged. In addition, test setups can be
stored with a set of data, so that field test results can be saved for later
analysis or printing.
All measurements, settings, and graphs are displayed on a sharp, clear,
backlighted liquid crystal display.
The Portable One Plus Access can be purchased with or without the
‘P1-IMD’ option, which allows generation and analysis of
Intermodulation Distortion test signals.
The Portable One Plus Access may also be purchased with the ‘EURZ’
option, which replaces the 150 Ω generator output impedance with
200 Ω, which is more common in European broadcast applications.
Another option is ‘P1DD-488’, which provides GPIB capabilities for
connection to computer-controlled automation systems.
Other options include a soft carrying case and optional filters for
specific band-limiting or weighting applications.
Any installed options are listed on the Options Label on the rear panel.
& For more
information on the
Options Label, see
page 2-8.
1
Introduction
Introducing the Portable One Plus Access
Portable One Plus Access User's Manual 1-3
