TEST 4.8 SELECTIVE FILTER -18.20dB -17.58dB -17.20dB PASS
TEST 5.0 A-WEIGHT FILTER -20.10dB -19.06dB -18.10dB PASS
TEST 5.1 A-WEIGHT FILTER -0.20 dB -0.02 dB 0.20 dB PASS
TEST 5.2 A-WEIGHT FILTER -6.50 dB -2.58 dB -0.50 dB PASS
TEST 5.3 CCIR WTG FILTER -20.80dB -19.87dB -18.80dB PASS
TEST 5.4 CCIR WTG FILTER -0.20 dB -0.06 dB 0.20 dB PASS
TEST 5.5 CCIR WTG FILTER 11.70dB 12.13dB 12.70dB PASS
TEST 5.6 CCIR WTG FILTER -1.20 dB -0.29 dB 1.20 dB PASS
TEST 5.7 QPK DETECTOR -0.20 dB 0.07 dB 0.20 dB PASS
TEST 5.8 AVG DETECTOR -0.20 dB -0.08 dB 0.20 dB PASS
TEST 6.0A 20 Hz THD+N 0.0000% 0.0011% 0.0025% PASS
TEST 6.1A 1 kHz THD+N 0.0000% 0.0011% 0.0025% PASS
TEST 6.2A 20 kHz THD+N 0.0000% 0.0013% 0.0025% PASS
TEST 6.3A 50 kHz THD+N 0.0000% 0.0024% 0.0100% PASS
TEST 6.4B 20 Hz THD+N 0.0000% 0.0011% 0.0025% PASS
TEST 6.5B 1 kHz THD+N 0.0000% 0.0010% 0.0025% PASS
TEST 6.6B 20 kHz THD+N 0.0000% 0.0013% 0.0025% PASS
TEST 6.7B 50 kHz THD+N 0.0000% 0.0024% 0.0100% PASS
TEST 6.8 IMD RESIDUAL 0.0000% 0.0010% 0.0025% PASS
TEST 7.0A RESIDUAL NOISE 0.000 V 1.131 uV 1.500 uV PASS
TEST 7.1B RESIDUAL NOISE 0.000 V 1.115 uV 1.500 uV PASS
TEST 8.0 20 Hz PHASE -2.0 deg 0.0 deg 2.0 deg PASS
TEST 8.1 1 kHz PHASE -2.0 deg 0.0 deg 2.0 deg PASS
TEST 8.2 20 kHz PHASE -2.0 deg -0.2 deg 2.0 deg PASS
TEST 9.0 WOW AND FLUTTER 0.950 % 1.002 % 1.050 % PASS
Passed Self Test
F
Self Test
Appendix F - Self Test
Portable One Plus Access User's Manual F-5
