Audio Precision Portable One Plus Access User Manual

ANALOG ANALYZER
ANALOG INPUT CHARACTERISTICS
Input Ranges
80 mV to 250 V in 10 dB steps
Maximum Rated Input
350 Vpk, 140 Vrms (dc to 20 kHz);
overload protected in all ranges
Input Impedance
Balanced (each side)
Nominally 100 kΩ // 150-200pF
Unbalanced
Nominally 100 kΩ // 150-200pF
Terminations
Selectable 600 Ω±1%; 1 Watt [+30 dBm]
maximum power
CMRR
80mV-2.5V ranges
≥70 dB, 50 Hz-20 kHz
8V-250V ranges
≥50 dB, 50 Hz-1 kHz
Input Related Crosstalk
≤-120 dB or 1 µV, whichever is greater
10 Hz-20 kHz
Level Meter Related (both channels)
Measurement Range
10 mV-140 V [-38 dBu to + 45 dBu] for
specified accuracy and flatness, useable to
<100 µV
Accuracy (1 kHz)
±0.1 dB + 100 µV
Flatness (1 kHz ref)
20 Hz-20 kHz
±0.05 dB
10 Hz-50 kHz
±0.2 dB
50 kHz-120 kHz
±0.50 dB (-3 dB BW typically >300 kHz)
Frequency Meter Related (both channels)
Measurement Range
10 Hz-200 kHz
Accuracy
±0.01% [±100 PPM]
Resolution
5 digits
Minimum Input
25 mV
G
Specifications
Appendix G - Specifications
Portable One Plus Access User's Manual G-3
