The tilt bail is used to elevate the front of the instrument for more
comfortable viewing. It is located on the bottom of the instrument, near
the front. Normally it will be latched into its storage position. To use
it, pivot it out toward the front panel and rest the instrument on it, as
shown in the following figure:
Tilt Bail
Figure 2-2. Tilt Bail
2 Setting Up
Getting Started Front Cover and Tilt Bail
2-2 Portable One Plus Access User's Manual
