Audio Precision Portable One Plus Access User Manual

.
FREQUENCY CONTROLS - These buttons and knob generally
control the generator frequency. They may also control other
parameters, depending on what is shown on the screen.
.
AMPLITUDE CONTROLS - These buttons and knob generally
control the generator amplitude. They may also control other
parameters, depending on what is shown on the screen.
.
INPUT CONTROL KEYS - These keys control which channel is
selected for measurement, and generator monitor connections.
.
OUTPUT CONTROL KEYS - These keys turn the generator
channels off and on. The state is indicated by nearby indicator
lights.
.
INSTRUMENT MODE KEYS - These keys select among the
major operating modes of the instrument and the current
display mode.
.
RECALL/SAVE KEY - This key provides access to a display
which allows test setups to be saved and recalled from memory.
.
MONITOR AND CONTRAST CONTROLS - The contrast
control adjusts the contrast of the LCD display. The MONITOR
knob controls the volume of the signal monitored by the internal
speaker or stereo headphones connected to the MONITOR jack.
.
GENERATOR OUTPUTS - These XLR jacks provide analog
signal output to the device-under-test.
.
ANALYZER INPUTS - These XLR jacks provide signal inputs to
the analyzer from the device-under-test.
& Generator
amplitude and
frequency control -
page 4-12.
& Input control -
page 4-16.
& Output control -
page 4-12.
& Instrument Mode
and Navigating - page
4-1.
& Recalling and
Saving - page 4-62.
& Monitor
Operation - page 4-8.
& Contrast control
- page 4-1.
& Generator
Outputs and Analyzer
Inputs - page 3-2.
2
Getting Started
Front Panel Overview Getting Started
Portable One Plus Access User's Manual 2-5
