FUSE REPLACEMENT DATA - This section shows what type
and rating of fuses should be used for every line voltage.
.
LINE VOLTAGE INDICATOR HOLES - These holes indicate
the line voltage currently configured.
.
POWER CORD CONNECTOR - This connects to a line cord to
provide power input.
.
POWER SWITCH - This switch turns the main power supply to
the Portable One Plus Access on (1) and off (0).
& Checking Line
Voltage - page 2-3.
& Connecting
Power - page 2-3.
& Checking Fuses -
page 10-5.
2
Getting Started
Rear Panel Overview Getting Started
Portable One Plus Access User's Manual 2-7
