16
Setting the ATW-DR3120/ATW-DR3120DAN
List of setting items
FREQUENCY MANUAL Set the operating frequency.
Gr/Ch
NAME Set the channel name.
AUDIO LINE/MIC Set the line/microphone level.
LEVEL Set the audio output level.
MIX OUTPUT Set whether to mix and output the
audio of the RECEIVER1 and
RECEIVER2 receivers.
SCAN Scan for open channels.
TX SYNC Set transmitters via IR SYNC.
SECURITY PIN Set the PIN code for security.
AES256 Set security with a higher level of
confidentiality.
UTILITIES RF MODE Set the RF mode.
LOCK Set this function to prevent the
receiver settings from being changed.
ANT PWR Set whether to turn power to the
antenna input jacks on or off.
Gr/Ch EDIT The channels that compose the
editable user groups (U1 and U2) can
be edited.
BACKUP
FREQ
Set the backup frequency.
AF METER Switch the level meter on the main
screen between receiver and
transmitter.
BRIGHTNESS Set the display brightness.
ACCESS Set the user access level.
RESET This returns the receiver settings to
their factory defaults.
VERSION This function displays product
information such as the version of the
receiver.
NETWORK DEVICE ID Set the receiver’s ID number.
IP SETTING Set the IP.
REMOTE
CTRL
Set the remote control.
SYSLOG Set whether to send the log message
to the Syslog server.
DISCOVERY Set automatic detection by the
application.
NTP Set the NTP (Network Time Protocol).
MAC
ADDRESS
Display the MAC address.
DANTE* INFO Display the device name and channel
label.
IP SETTING Set the DANTE’s IP.
MAC
ADDRESS
Display the MAC address.
VERSION This function displays product
information, such as the version of
the DANTE.
* ATW-DR3120DAN only
Setting the operating frequency
Setting manually
1. From the menu screen, turn the control dial, select
[FREQUENCY], and then press the control dial.
2. Select [MANUAL] and press the control dial.
3. Turn the control dial to set the first 3 digits. When finished
setting them, press the control dial.
4. Turn the control dial to set the last 3 digits. When finished
setting them, press the control dial.
• The setting is complete.
Setting by group/channel
1. From the menu screen, turn the control dial, select
[FREQUENCY], and then press the control dial.
2. Select [Gr/Ch] and press the control dial.
3. Turn the control dial to set the group. When finished setting it,
press the control dial.
4. Turn the control dial to set the channel. When finished setting it,
press the control dial.
• The setting is complete.
Setting the channel name
The characters that can be entered are shown below.
• The maximum number of characters that can be entered is 8.
Alphabetic (uppercase letters) Numeric
Symbols (_, +, −, #, &, period) Space
1. From the menu screen, turn the control dial, select [NAME], and
then press the control dial.
2. Turn the control dial, select the desired character, and then
press the control dial.
• The character is input and the cursor moves.
3. Repeat the operation in Step 2 to enter all characters.
4. Turn the control dial, select [End], and then press the control dial.
• The setting is complete.
To Next Page
