23
Setting the ATW-DT3101/ATW-DT3102
List of setting items
FREQUENCY Manual Set the transmission frequency.
Gr/Ch
NAME Set the channel name.
GAIN Adjust the microphone input gain.
INPUT* Set the device connected to the input
connector of the transmitter to [MIC]
(microphone) or [INST] (guitar cable,
etc.).
SENSITIVITY* Select the microphone input gain
from 0dB and +10dB.
RF POWER Set the transmission output.
HPF Set the HPF (High-Pass Filter).
LOCK Set the button lock.
Fn BUTTON Set the function allocation for the
function button.
MUTE MODE* Set mute mode.
SECURITY PIN Set the PIN code for security.
AES256 Clear the AES-256 encryption when it
has been set.
UTILITIES RF MODE Set the RF mode.
TEST TONE
Output a test signal from the transmitter.
BATTERY Set the type of batteries used.
LED Set whether to keep the indicator
lamp turned on at all times.
ACCESS Set the user access level.
RESET This returns the transmitter settings
to their factory defaults.
VERSION This function displays the version of
the transmitter.
* ATW-DT3101 only
Setting the transmission frequency
Setting manually
1. From the menu screen, press the UP/DOWN button to select
[FREQUENCY], and then press the SET button.
.000 MHz 000
FREQUENCY
2. After selecting [Manual], press the SET button.
Manual
FREQUENCY
3. Press the UP/DOWN button to set the first 3 digits. After
completing the setting, press the SET button.
4. Press the UP/DOWN button to set the last 3 digits. After
completing the setting, press the SET button.
• The setting is complete.
Setting by group/channel
1. From the menu screen, press the UP/DOWN button to select
[FREQUENCY], and then press the SET button.
.000 MHz 000
FREQUENCY
2. After selecting [Gr/Ch], press the SET button.
Gr/Ch
FREQUENCY
3. Press the UP/DOWN button to set the group. After completing
the setting, press the SET button.
4. Press the UP/DOWN button to set the channel. After completing
the setting, press the SET button.
• The setting is complete.
Setting the channel name
The characters that can be entered are shown below.
• The maximum number of characters that can be entered is 8.
Alphabetic (uppercase letters) Numeric
Symbols (_, +, −, #, &, period) Space
1. From the menu screen, press the UP/DOWN button to select
[NAME], and then press the SET button.
NAME
2. Press the UP/DOWN button to select a desired character and
press the SET button.
• The character is input and the cursor moves.
3. Repeat the operation in Step 2 to enter all characters.
• If you don’t enter 8 characters, press the UP/DOWN button to select
[END], and then press the SET button.
4. After entering the 8th character, press the SET button.
• [END] is displayed.
5. Press the SET button.
• The setting is complete.
