Audio Technica AT-LP3XBT User Manual

11
Preparation for use
Setting up the turntable
Position the product on a level surface.
To avoid the effects of vibrations and acoustic pressure, do not mount the product next to such items as speakers.
The product may pick up radio static if placed next to a radio. Therefore, try to keep the product away from radios.
If the product is near equipment (cell phone, etc.) that emits strong radio waves, noise may occur.
Placing the platter and the felt mat
This product requires some assembly before using it for the first time. Do not connect the AC adapter until assembly is
complete.
1
Set the platter on the spindle.
Make certain that the platter is fully seated on the spindle.
Align one of the openings with the position of the motor pulley (brass-colored) (See the diagram below).
To avoid damaging the spindle when seating the platter, align the positions of the spindle and the platter’s
hole, and then slowly seat the platter.
1
1
Motor pulley (brass-colored)
2
Attach the drive belt to the motor pulley (brass-colored).
Align one of the platter openings with the brass motor pulley, and, while pulling both ends of the red ribbon
that comes attached to the belt, place the belt on the motor pulley, as per the diagram. When doing this, be
careful not to twist the belt.

Audio Technica AT-LP3XBT Specifications

General

Type	Belt-drive audio turntable
Operation	Fully automatic
Motor type	DC motor
Product color	White
Wow & flutter	0.2 %
Nominal speeds	33 1/3, 45 RPM
Platter material	Aluminum
Signal-to-Noise Ratio (SNR)	60 dB
Frequency range	2402 - 2480 Hz
Power supply type	AC
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
Power consumption (typical)	2 W
Quantity	1
Cables included	RCA
Dust cover included	Yes
Bluetooth version	5.2
Bluetooth profiles	A2DP
USB ports quantity	-

Weight and Dimensions

Depth	374 mm
Width	435.6 mm
Height	128 mm
Weight	5000 g
