Using the product with wireless connection
21
At 45 RPM
To play a 45 RPM record, attach the 45 RPM adapter.
3
Turn on the power of the Bluetooth device.
When this product is correctly connected to the Bluetooth device, the product’s Bluetooth indicator LED lights
in blue.
When the Bluetooth indicator LED lights in red, press the wireless function button to reconnect to the
Bluetooth device.
If amplifiers or active speakers already connected to the product with wires are left on, sound will be played
from both the wire-connected equipment and from the Bluetooth device when it is connected to the product
via Bluetooth. Only turn on the device you want to use for playback.
Automatic operation
Lower the volume of the wireless headphones, wireless speakers, etc. sufficiently.
1
Select the size with the size selector.
Select “12"” for an LP record with a 12" diameter, and “7"” for a 45 RPM record with a 7" diameter.
2
Press the speed with the platter speed button.
Select “33” for a 33-1/3 RPM record and “45” for a 45 RPM record.
3
Press the START button.
Do not subject the product to strong impact during playback.

Audio Technica AT-LP3XBT Specifications

General

Type	Belt-drive audio turntable
Operation	Fully automatic
Motor type	DC motor
Product color	White
Wow & flutter	0.2 %
Nominal speeds	33 1/3, 45 RPM
Platter material	Aluminum
Signal-to-Noise Ratio (SNR)	60 dB
Frequency range	2402 - 2480 Hz
Power supply type	AC
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
Power consumption (typical)	2 W
Quantity	1
Cables included	RCA
Dust cover included	Yes
Bluetooth version	5.2
Bluetooth profiles	A2DP
USB ports quantity	-

Weight and Dimensions

Depth	374 mm
Width	435.6 mm
Height	128 mm
Weight	5000 g
