Audio Technica AT-LP3XBT User Manual

46
Specifications
Communication specifications
Communication system
Bluetooth version 5.2
RF output
2.5 mW EIRP
Maximum communication
range
Line of sight - approx. 10 m (33')
Frequency band
2.402 GHz to 2.480 GHz
Modulation method
GFSK, Pi/4DQPSK, 8DPSK
Compatible Bluetooth profile
A2DP
Supported codec
Qualcomm
®
aptX
™
Adaptive audio, Qualcomm
®
aptX
™
audio, SBC
Turntable specifications
Type
Belt-drive, fully automatic operation
Motor
DC motor
Drive method
Belt drive
Speeds
33-1/3 RPM, 45 RPM
Turntable platter
Die-cast aluminum
Wow and flutter
< 0.2% WRMS (33 RPM) at 3 kHz
Signal-to-noise ratio
> 60 dB
Output levels
PHONO: 4.0 mV nominal at 1 kHz, 5 cm/sec
LINE: 252 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-amp gain
36 dB nominal, RIAA equalized
Tonearm specifications
Type
Static balanced straight tonearm
Effective length
221.5 mm
Overhang
19 mm
Maximum tracking error angle
Less than 3.0°
Stylus pressure adjustment
range
1 to 4 g
Applicable cartridge weight
range (including headshell)
14.5 to 20 g

Audio Technica AT-LP3XBT Specifications

General

Type	Belt-drive audio turntable
Operation	Fully automatic
Motor type	DC motor
Product color	White
Wow & flutter	0.2 %
Nominal speeds	33 1/3, 45 RPM
Platter material	Aluminum
Signal-to-Noise Ratio (SNR)	60 dB
Frequency range	2402 - 2480 Hz
Power supply type	AC
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
Power consumption (typical)	2 W
Quantity	1
Cables included	RCA
Dust cover included	Yes
Bluetooth version	5.2
Bluetooth profiles	A2DP
USB ports quantity	-

Weight and Dimensions

Depth	374 mm
Width	435.6 mm
Height	128 mm
Weight	5000 g
