36
Replacing the belt
The belt is a consumable part. Replace the belt if the speed of playback slows down or irregular rotation occurs. As a
rule of thumb, we suggest replacing the belt once a year.
Before replacing the belt, be sure to disconnect the product’s AC adapter from the outlet.
1
Remove the felt mat.
2
First remove the belt from the motor pulley (brass-colored), remove the platter, turn the platter over,
and then remove the old belt.
Place your thumbs in the openings and pull up strongly.
3
Place the new belt around the inner circle.
Be careful not to twist the belt while doing this.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Audio Technica AT-LP3XBT and is the answer not in the manual?

Audio Technica AT-LP3XBT Specifications

General IconGeneral
TypeBelt-drive audio turntable
OperationFully automatic
Motor typeDC motor
Product colorWhite
Wow & flutter0.2 %
Nominal speeds33 1/3, 45 RPM
Platter materialAluminum
Signal-to-Noise Ratio (SNR)60 dB
Frequency range2402 - 2480 Hz
Power supply typeAC
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current0.6 A
Power consumption (typical)2 W
Quantity1
Cables includedRCA
Dust cover includedYes
Bluetooth version5.2
Bluetooth profilesA2DP
USB ports quantity-
Weight and Dimensions IconWeight and Dimensions
Depth374 mm
Width435.6 mm
Height128 mm
Weight5000 g
