Audio Technica AT-LP3XBT User Manual

Replacing the belt
37
1
1
Belt
4
Attach the platter.
Align one of the openings with the position of the motor pulley (brass-colored).
1
2
1
Opening
2
Motor pulley (brass-colored)
5
Place the belt on the motor pulley (brass-colored).
Grasp the belt that was attached in step 3 and, while pulling it, place it on the brass motor pulley.

Audio Technica AT-LP3XBT Specifications

General

Type	Belt-drive audio turntable
Operation	Fully automatic
Motor type	DC motor
Product color	White
Wow & flutter	0.2 %
Nominal speeds	33 1/3, 45 RPM
Platter material	Aluminum
Signal-to-Noise Ratio (SNR)	60 dB
Frequency range	2402 - 2480 Hz
Power supply type	AC
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
Power consumption (typical)	2 W
Quantity	1
Cables included	RCA
Dust cover included	Yes
Bluetooth version	5.2
Bluetooth profiles	A2DP
USB ports quantity	-

Weight and Dimensions

Depth	374 mm
Width	435.6 mm
Height	128 mm
Weight	5000 g
