Audio Technica AT-LP3XBT User Manual

Specifications
47
Cartridge and headshell specifications
Cartridge Model
AT-VM95C
Cartridge Type
VM
Recommended load impedance
47,000 ohms
Output voltage
4.0 mV (mV at 1 kHz, 5 cm/sec)
Stylus
0.6 mil bonded conical
Cantilever
Aluminum pipe
Tracking force range
1.8 to 2.2 g (standard 2.0 g)
Cartridge weight
6.1 g (0.22 oz)
Headshell model
AT-HS3 BK
Headshell weight
11.1g (0.39oz) (including lead wires)
10.3g (0.36oz) (excluding lead wires)
Headshell overhang adjustment
± 8 mm
General specifications
Power supply requirements
100 to 240 V, 50/60 Hz, 0.6 A Max.
Power consumption
2 W
AC Adapter
12 V, 0.5 A
Dimensions
435.6 mm (17”) × 374 mm (15”) × 128 mm (5.0”) (W × D × H)
Weight
5.0 kg (11 lbs)
Accessories
Dust cover, Felt mat, Platter (with drive belt), Dust cover hinges,
Counterweight, Headshell (AT-HS3 BK) with VM stereo cartridge (AT-VM95C),
45 RPM adapter, RCA audio cable (Approx. 1.0 m (3.3')), AC adapter (Approx.
1.5 m (4.9'))
Replacement stylus (sold
separately)
AT-VMN95C
Replacement headshell (sold
separately)
AT-HS3 BK
Replacement belt (sold
separately)
AT-LP3XBT exclusive belt
For product improvement, the product is subject to modification without notice.

Audio Technica AT-LP3XBT Specifications

General

Type	Belt-drive audio turntable
Operation	Fully automatic
Motor type	DC motor
Product color	White
Wow & flutter	0.2 %
Nominal speeds	33 1/3, 45 RPM
Platter material	Aluminum
Signal-to-Noise Ratio (SNR)	60 dB
Frequency range	2402 - 2480 Hz
Power supply type	AC
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
Power consumption (typical)	2 W
Quantity	1
Cables included	RCA
Dust cover included	Yes
Bluetooth version	5.2
Bluetooth profiles	A2DP
USB ports quantity	-

Weight and Dimensions

Depth	374 mm
Width	435.6 mm
Height	128 mm
Weight	5000 g
