MediaPack SIP
MediaPack SIP User’s Manual 58 Document #: LTRT-65405
Table 5-2: Proxy & Registration Parameters (continues on pages 57 to 60)
Parameter Description
Third Redundant Proxy IP
Address
[ProxyIP]
IP addresses of the third redundant Proxy you are using.
Enter the IP address as FQDN or in dotted format notation (for example 192.10.1.255).
You can also specify the sele
cted port in the format: <IP Address>:<port>.
Note 1: This parameter is available only if you select ‘Yes’ in the ‘Enable Proxy’ field.
Note 2: When port number is specified, DNS SRV queries aren’t performed, even if
‘EnableProxySRVQuery’ is set to 1.
ini file note: The IP addresses of the third redundant Proxy is defined by the forth
repetition of the ini file parameter ‘ProxyIP’.
Enable SRV Queries
[EnableSRVQuery]
Enables the use of DNS Service Record (SRV) queries to resolve Proxy and Registrar
servers and to resolve all domain names that appear in the Contact and Record-Route
headers.
Disable [0] (default).
Enable [1].
If enabled and the Proxy / Registrar IP address parameter or the domain name in the
Contact / Record-Route headers contains a domain name without port definition, an SRV
query is performed. The gateway uses the first host name received from the SRV query.
The gateway then performs DNS A-record query for the host name to locate an IP
address.
If the Proxy / Registrar IP address parameter or the domain name in the Contact / Record-
Route headers contains a domain name with port definition, the gateway performs a
regular DNS A-record query.
To enable SRV queries only for Proxy servers, set the parameter ‘EnableProxySRVQuery’
to 1.
Enable Proxy SRV Queries
[EnableProxySRVQuery]
Enables the use of DNS Service Record (SRV) queries to discover Proxy servers.
Disable [0] = Disabled (default).
Enable [1] = Enabled.
If enabled and the Proxy IP address parameter contains a domain name without port
definition (e.g., ProxyIP = domain.com), an SRV query is performed. The SRV query
returns up to four Proxy host names and their weights. The gateway then performs DNS
A-record queries for each Proxy host name (according to the received weights) to locate
up to four Proxy IP addresses. Therefore, if the first SRV query returns two domain
names, and the A-record queries return 2 IP addresses each, no more searches are
performed.
If the Proxy IP address parameter contains a domain name with port definition (e.g.,
ProxyIP = domain.com:5080), the gateway performs a regular DNS A-record query.
Note: When enabled, SRV queries are used to discover Proxy servers even if the
parameter ‘EnableSRVQuery’ is disabled.
Redundancy Mode
[ProxyRedundancyMode]
Parking [0] = Gateway continues working with the last active Proxy until the next failure
(default).
Homing [1] = Gateway always tries to work with the primary Proxy server (switches back
to the main Proxy whenever it is available).
Note: To use Redundancy Mode, enable Keep-alive with Proxy option (Enable Proxy
Keep Alive = Yes).
Is Proxy Trusted
[IsTrustedProxy]
This parameter isn’t applicable and must always be set to ‘Yes’ [1].
The parameter ‘AssertedIdMode’ should be used instead.
Enable Registration
[IsRegisterNeeded]
No [0] = Gateway doesn’t register to Proxy / Registrar (default).
Yes [1] = Gateway registers to Proxy / Registrar when the device is powered up and every
RegistrationTime seconds.
Note: The gateway sends a REGISTER request for each channel or for the entire gateway
(according to the AuthenticationMode parameter).
Registrar Name
[RegistrarName]
Registrar Domain Name.
If specified, the name is used as Request-URI in REGISTER messages.
If isn’t specified (default), the Registrar IP address or Proxy name or Proxy IP address is
used instead.
