MediaPack SIP User’s Manual 5. Configuring the MediaPack
Version 4.6 49 June 2005
5.3.1 Using Internet Explorer to Access the Embedded Web Server
Internet explorer’s security settings may block access to the gateway’s Web browser if they’re
configured incorrectly. In this case, the following message is displayed:
Unauthorized
Correct authorization is required for this area. Either your browser does not perform
authorization or your authorization has failed. RomPager server.
¾ To troubleshoot blocked access to Internet Explorer
™
, take these 2
steps
1. Delete all cookies from the Temporary Internet files. If this does not clear up the problem, the
security settings may need to be altered (refer to Step 2).
2. In Internet Explorer, Tools, Internet Options select the Security tab, and then select Custom
Level. Scroll down until the Logon options are displayed and change the setting to Prompt
for username and password and then restart the browser. This fixes any issues related to
domain use logon policy.
5.4 Getting Acquainted with the Web Interface
Figure 5-2 shows the general layout of the Web Interface screen.
Figure
5-2: MediaPack Web Interface
The Web Interface screen features the following components:
• Title bar - contains three configurable elements: corporate logo, a background image and the
product’s name. For information on how to modify these elements, refer to Section
10.5 on
page 206.
Main Menu
Ba
Corporate
Lo
o
Submenu
Ba
Title Bar
Main Action
Frame
Control
Protocol
To Next Page
