MediaPack SIP User’s Manual 5. Configuring the MediaPack
Version 4.6 81 June 2005
5.5.4 Configuring the Routing Tables
Use this submenu to configure the gateway’s IPÆTel and TelÆIP routing tables and their
associated parameters.
5.5.4.1 General Parameters
Use this screen to configure the gateway’s IPÆTel and TelÆIP routing parameters.
¾ To configure the general parameters under Routing Tables, take these 4
steps:
1. Open the ‘General Parameters’ screen (Protocol Management menu > Routing Tables
submenu > General option); the ‘General Parameters’ screen is displayed.
Figure
5-11: Routing Tables, General Parameters Screen
2. Configure the general parameters under ‘Routing Tables’ according to Table
5-10.
3. Click the Submit button to save your changes.
4. To save the changes so they are available after a power fail, refer to Section
5.9 on page
161.
Table
5-10: Routing Tables, General Parameters (continues on pages 81 to 82)
Parameter Description
Add Hunt Group ID as Prefix
[AddTrunkGroupAsPrefix]
No [0] = Don’t add hunt group ID as prefix (default).
Yes [1] = Add hunt group ID as prefix to called number.
If enabled, then the hunt group ID is added as a prefix to the destination phone number
for TelÆIP calls.
Note 1: This option can be used to define various routing rules.
Note 2: To use this feature you must configure the hunt group IDs.
Add Port Number as Prefix
[AddPortAsPrefix]
No [0] = Disable the add port as prefix service (default).
Yes [1] = Enable the add port as prefix service.
If enabled, then the gateway’s port number (single digit in the range 1 to 8 for 8-port
gateways, two digits in the range 01 to 24 in MP-124) is added as a prefix to the
destination phone number for TelÆIP calls.
Note: This option can be used to define various routing rules.
