RemedyDescriptionSignal
Cool down, wait.Motor protection tripped.
THERMAL FAULT
If the fault indication display persists after
cooling down:
Set selector switch to position Local control
(LOCAL) or reset fault indication via Reset
push button.
Or:
Perform reset command via fieldbus.
Check fuse F4.
For further information:
1.
Go to group
D0: Press C and hold it
down until diagnostic indication
D0 is
displayed.
2.
Go to diagnostic indication
D4: Press
4 x.
The controls configuration is incorrect.
CONFIGURATION FAULT
10.2.3 Status indication S2 - warnings
Faults are indicated within the status indication
S2:
WARNING IND. S2
NO WARNINGS
Table 13: Description of the warnings
RemedyDescriptionSignal
No warnings have occurred.
NO WARNINGS
Set the running time(MONITOR TRIG-
GERS
parameter) in accordance with the
actual running time.
Preset running time for a travel between end
position OPEN and end position CLOSED
has been exceeded.
WARNING OPER. TIME
Check tripping behaviour of end position
switches.
Verify actuator mechanics.
Check modulating behaviour.Preset values for max. starts/h or max. run-
ning time/h have been exceeded.
WARNING STARTS/RUN
Increase dead time.
Reduce number of setpoint changes.
Operate actuator into both end positions
(OPEN and CLOSED).
Position transmitter (potentiometer or RWG)
is not standardised.
INTERNAL FEEDBACK
For further information:
1.
Go to group
D0: Press C and hold it
down until diagnostic indication
D0 is
displayed.
2.
Go to diagnostic indication
D3: Press
3 x.
Internal warnings have occurred.
INTERNAL WARNING
Check position transmitter signal.
1.
Go to group
D0: Press C and hold it
down until diagnostic indication
D0 is
displayed.
2.
Go to diagnostic indication
D7, D8 or
D9: Press either 7, 8 or 9 times.
Signal loss of position transmitter
FEEDBACK E2 LOSS
Check position transmitter wiring.
Check
POSITION E2 parameter. The
setting must correspond to the wiring dia-
gram.
Check wiring.Signal loss of setpoint
SETPOINT E1 LOSS
Check wiring.Signal loss of torque source
TORQUE E6 LOSS
58
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electromechanic
Corrective action AC 01.1 Intrusive Modbus RTU
