AUMA SG 05.1-F07 User Manual

RemedyDescriptionSignal
Check wiring.Signal loss of the analogue input 1 of the
parallel interface (only for Fieldbus/standard
interface combinations)
I/O ANLOG IN1 LOSS
Check wiring.Signal loss of the analogue input 2 of the
parallel interface (only for Fieldbus/standard
interface combinations)
I/O ANLOG IN2 LOSS
Check wiring.Signal loss of actual process value E4 (only
if PID controller is available and active)
P-FEEDBACK E4 LOSS
Check wiring.Signal loss of FO cable (for bus with FO loop
topology only)
FIBER OPTIC LOSS
Check wiring.Signal loss of analogue input 1
ANALOG IN1 BUS1 LOSS
Check wiring.Signal loss of analogue input 2
ANALOG IN2 BUS1 LOSS
10.2.4 Status indication S3 - causes for not ready remote
The causes for the
NOT READY IND. fault signals (from status indication S0) are
displayed within status indication
S3.
NOT READY IND. S3
READY
Table 14: Description of the fault indications
DescriptionSignal
Actuator can be operated from REMOTE.
READY
Actuator cannot be operated from REMOTE as the selector switch is in position LOCAL
or OFF (0).
NOT REMOTE
The EMERGENCY operation mode is active.
EMERGENCY MODE
For combination fieldbus/standard interface function:
Operation via parallel interface.
EXTERNAL CONTROLS
The EMERGENCY STOP button has been operated.
EMCY STOP ACTIVE
Actuator locked (only set for special applications e.g. for by-pass function).
ACTUATOR LOCKED
10.3 Fuses
Hazardous voltage!
Electric shock possible.
→
Disconnect device from the mains before opening.
10.3.1 Fuses within the actuator controls
Fuses F1 and F2 can be accessed after removing the cover [1] on the rear side.
Fuses F3, F4, and F5 are located on the power supply unit and can be accessed
after removing the electrical connection [2].
