12.4 Service conditions
Any positionMounting position
Approved for indoor and outdoor installationUse
Refer to name plate
Standard:
●
IP 67
Options:
●
IP 68
●
IP 68-DS
●
IP 67-DS
According to AUMA definition, enclosure protection IP 68 meets the following requirements:
●
Water depth: Maximum 8 m head of water
●
Duration of submersion in water: maximum of 96 hours
●
Up to 10 operations during submersion
●
Modulating duty is not possible during submersion.
(DS = Double Sealed = terminal compartment additional sealed against interior)
Enclosure protection according
to EN 60529
Standard:
KN: Suitable for installation in industrial units, in water or power plants with a low pollutant
concentration
Options:
●
KS: Suitable for installation in occasionally or permanently aggressive atmosphere with
a moderate pollutant concentration (e.g. in wastewater treatment plants, chemical industry)
●
KX: Suitable for installation in extremely aggressive atmospheres with high humidity and
high pollutant concentration
●
KX-G: same as KX, however aluminium-free version (outer parts)
Corrosion protection
Standard: Two-component iron-mica coatingFinish coating
Standard: AUMA silver-grey (similar to RAL 7037)Colour
Refer to name plate
Standard:
●
–25 °C to +70 °C
Options:
●
–40 °C to +70 °C
●
–50 °C to +70 °C
Low temperature versions inc. heating system for connection to external power supply 230
V AC or 115 V AC.
Ambient temperature
Open-close duty (operating cycles OPEN - CLOSE - OPEN):
SG 05.1 – SG 07.1: 20,000
SG 10.1: SG 15,000
SG 12.1: 1, 000
Modulating duty:
14)
SGR 05.1 – SGR 12.1: 2.5 million modulating steps
Lifetime
Refer to separate technical dataWeight
12.5 Accessories
AUMATIC mounted separately from the actuator, including plug/socket connector. Connecting
cables on request. Recommended for high ambient temperatures, difficult access, or in case
of heavy vibration during service
Wall bracket
15)
The control voltage of the reversing contactors is interrupted by operating the EMERGENCY
STOP button.
EMERGENCY STOP button
16)
COM-AC. An interface cable is required for the standard infra-red programming interface.Programming software for PC
14) The lifetime depends on the load and the number of starts. A high starting frequency will rarely improve the modulating accuracy. To
reach the longest possible maintenance and fault-free operating time, the number of starts per hour chosen should be as low as permis-
sible for the process
15) Cable length between actuator and AUMATIC max. 100 m. Not suitable for version with potentiometer in the actuator. Instead of the
potentiometer, an RWG has to be used.
16) Only in combination with reversing contactors and AUMATIC AC 01.1 in enclosure protection IP 67 or IP 68
69
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electromechanic
AC 01.1 Intrusive Modbus RTU Technical data
