6. USE
The barrier must be used in compliance with safety instructions (Ch. 1. ).
Never operate the barrier without bumpers (10, Ch. 2.1. ), or without an arm.
6.1. First startup
1. Before startup, review the procedures described in Chapters 4. and 5.
2. Engage the circuit breaker (20).
3. If the barrier is equipped with heater turn on the heater circuit breaker (24).
4. On the control board:
- Select the menus language (left key ◄).
- Set all the parameters of the QUICK START menu.
- Make sure to save these modifications (QUICK START ► MEMORY ► Save).
5. Switch off the power supply network, wait 10 s and turn it on again.
6. Proceed to run a few electrical opening and closing tests by pressing the control board’s OK button or
by means of the available command mode (push-button box, transmitter/receiver, etc.).
Check that the arm is correctly positioned in the open (vertical) and closed (horizontal) positions.
Refer to the corresponding adjustment where necessary (Ch. 4. and 5. ).
7. Check that the variable speed controller (17, Ch. 2.1.) shows a range of positive values when the
obstacle opens and the negative values when it closes. If this is not the case, the motor is running in
reverse and you must reverse 2 phases of the motor, after having turned off the circuit breaker (20).
8. Check that all the possible safeties and options are operating properly.
9. Proceed to maintenance (Ch. 6.5. ).
6.2. Daily startup
Follow steps 1, 3, 5, 7 in Chapter 6.1.
6.3. Turning off the power
Trip the circuit breaker (20). If the barrier is equipped with heater also turn off the heater circuit breaker (24).
