6.4. Manual opening of the arm
The procedure to be followed to lift the arm manually differs depending on the installed options, as
summarised in the following table:
BL CONFIGURATION PROCEDURE
Without lifting of the
arm
Without lock  Cut the power (circuit breaker (20, Ch. 2.1. ) on OFF)
 Lift the arm manually.
With lock NO  Cut the power (circuit breaker (20, Ch. 2.1. ) on OFF)
 Lift the arm manually.
With lock NC  Cut the power (circuit breaker (20, Ch. 2.1. ) on OFF)
 Open the cover.
 Spread the clips (83) to manually unlock the locking pin
(84) (see Ch. 2.3. ).
 Lift the arm manually.
With automatic lifting
of the arm
Without lock  Cut the power (circuit breaker (20, Ch. 2.1. ) on OFF)
With lock NO  Cut the power (circuit breaker (20, Ch. 2.1. ) on OFF)
With lock NC  Cut the power (circuit breaker (20, Ch. 2.1. ) on OFF)
 Open the cover.
 Spread the clips (83) to manually unlock the locking pin
(84) (see Ch. 2.3. ).
 Lower the arm manually if in the up position. If the arm is
in the down position it should lift by itself in the open
position.
