7. TECHNICAL SPECIFICATIONS
Electrical power supply: 120V~ (± 10%)/60Hz
Nominal Power consumed: 450 W
Ambient operating temperature:
-20°C to +50°C [-4°F to 122°F]
(-25°C [-13°F] with optional 250W heater
(-45°C [-49°F] with optional 500W heater)
Average relative humidity: 95% without condensation
Maximum wind speed (without disrupting the operation): 120km/h [74.6 mi/h]
Protection index: IP44
Net weight (without arm): 220 kg (BL40)
230 kg (BL41)
250 kg (BL43)
250 kg (BL46)
