p 3/58
Technical Manual NAM-BL4x-MT-EN-C
The information in this document is the property of Automatic Systems and is confidential. The consignee withholds from using it for anything other than the use of the products or the execution of the
project to which they belong and withholds from communicating it to third parties without prior written agreement from Automatic Systems. Document subject to change without prior notice.
TABLE OF CONTENTS
1. SAFETY WARNINGS 4
2. DESCRIPTION 6
2.1. Location of the components 6
2.2. Operating principle 7
2.3. Mechanical locking of the arm 8
3. AS1320 CONTROL BOARD 10
3.1. PRDSTD – BL_xxx menu: Troubleshooting and monitoring 12
3.2. QUICK START menu: Quick configuration 19
4. INSTALLATION 27
4.1. Storing the equipment before installation 27
4.2. Positioning the equipment 27
4.3. Assembly of the round arm for BL40 28
4.4. Assembly of the central round arm for BL41 30
4.5. Assembly of the oval arm for BL43 & BL44 32
4.6. Assembly of the arm with folding fence for BL46 34
4.7. Electrical connections 40
5. ADJUSTMENTS 41
5.1. Setting the parameters for the variable speed controller 41
5.2. Adjusting the balancing springs 42
5.3. Adjusting the position sensors 45
6. USE 46
6.1. First startup 46
6.2. Daily startup 46
6.3. Turning off the power 46
6.4. Manual opening of the arm 47
6.5. Maintenance 48
6.6. Troubleshooting 49
7. TECHNICAL SPECIFICATIONS 51
8. DIMENSIONS 52
9. WIRING DIAGRAMS 54
9.1. Control blocks assignment 55
