16
AM800, AM808 & AM888 Dominator Instruction Manual
6.6.2 To Erase Programmed Codes
If the Code Set button is pressed and held on for 6 seconds, the LED will
blink rapidly for one second to indicate that all programmed codes have been
erased (Fig 6.6.2).
6.6.3 Installation of Wall Mounted Transmitter
Refer to the below warning before installing the wall transmitter (Fig 6.6.3).
To set the transmitter codes refer to Section 6.6.1.
Fig.6.6.2
Fig.6.6.3
WARNING! The manufacturer is not responsible for any radio
or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user’s
authority to operate the equipment.
IMPORTANT WARNING
LOCATE THE WALL MOUNTED REMOTE CONTROL:
(1) WITHIN SIGHT OF DOOR.
(2) AT MINIMUM HEIGHT OF 5 FEET ABOVE FLOORS,
LANDINGS, STEPS OR OTHER ADJACENT WALKING
SURFACE SO SHALL CHILDREN ARE NOT ABLE TO
REACH IT, AND
(3) AWAY FROM MOVING PARTS OF THE DOOR.
(4) PLACE THE ATTACHED ENTRAPMENT WARNING LABEL
ON WALL NEXT TO WALL MOUNTED TRANSMITTER.
USE AN ADDITIONAL MECHANICAL MEANS (PLATE,
BOARD, ETC.), WHICH CAN SECURE THE LABELS
TO SURFACES TO WHICH THE ADHESIVE WILL NOT
ADHERE.
(5) DO NOT REMOVE OR PAINT OVER THIS LABEL.
6.6 Coding Transmitters
