AM800, AM808 & AM888 Dominator Instruction Manual
9. Spare Parts List
Item Part # Description Item Part # Description
1 72250 EXTRUSION 3150 VP2 (33010521) 37 14057 TERMINAL BLOCK SHIELD (07010480-B)
2 64594 TENSION SUPPORT ASSY (07100671) 38 65421 TERMINAL BLOCK 500/02DS 2 POS
3 64590 TENSION BRACKET (07100610) 39 10361 PAN HEAD SCREW W/T.L.WASHER M3x 14
4 63985 HEX SHAFT 10-40 (07100621) 40 76707 VARISTOR V300LA40AP
5 10602 SHOULDER SCREW M8X65 (07100630-A) 41 72330 MAIN COVER AM800 GR SP
6 64591 CLAMPING BRACKET VP1 (07100600-A) 42 41703 LED LIGHT LT04-2.00 W/HARNESS 300mm
7 64597 PULLEY SUPPORT (07100130-B) 43 65416 LED BRACKET PA1000 (41030350)
8 64313 FLANGE BUSH 16-10 (07100150) 44 10371 PAN HEAD SCREW W/T.L.WASHER M3 x 8
9 64697 SPROCKET 12T-12.7 (07100140) 45 72310 LIGHT DIFFUSER LEFT VP2
10 62963 CHAIN IDLER (07100640) 46 72311 LIGHT DIFFUSER RIGHT VP2
11 62941 CHAIN INDEX V3 (07100580-A) 47a 85530 AM-800 DCB08-1.20 NW SPARE
12 63005 CHAIN 1/2”X1/8” (487 LINKS) W/2 CL 47b 85535 AM-808 DCB08-1.20 NW SPARE
13 62950 CHAIN JOINT LINK 47c 85540 AM-888 DCB08-1.20 NW SPARE
14 71643 CHAIN CLIP IM KIT 48a 72306 BACK COVER AM-800 GR AY
15 64025 TIMING PULLEY 16T10 ASSY 48b 72307 BACK COVER AM-808 GR AY
16 62964 TIMING IDLER (07100660-A) 48c 72308 BACK COVER AM-888 GR AY
17 63007 TIMING BELT T10-6280 49 72312 CONTROLS COV SP VP2 T/GR
18 64593 TIMING INDEX CLAMP (07100770-A) 50 10497 FLANGE TAPTITE SCREW “S” M4x10
19 64596 TIMING INDEX SLEEVE (07100760-A) 51 10603 SHOULDER SCREW 5-M4x6 (07100290)
20 64598 BELT GUIDE VP2 (330110170-C) 52 65790 PIN 0890 (22010290-A)
21 60274 SHUTTLE VP1 ASSY (07100703) 53 62551 CLEVIS PIN 0829 (07100690)
22 62786 METAL CHASSIS VP1-3 PA (07120322) 54 10110 HEX HEAD SCREW M8 x 25
23 65603 GROMMET 101422 (01060350-A) 55 10148 HEX SERRATION FLANGE NUT M8 (BLACK)
24 65611 CORD GRIP GROMMET SB6N-4 56 10720 PIN SNAP SSP 8 ZNU 31080
25 65672 POWER CORD U.S. 1.5m W2PIN+1RING 57 62511 DOOR BRACKET (05021100)
26 12150 WIRE EARTH ASSY 230L (01060500-B) 58 62515 DOOR BRACKET LOCATOR (05021120)
27a 60379 GEARED MOTOR ASSY 16V2 55RPM 59 62522 WALL BRACKET TS01 (22010300)
27b 60339 GEARED MOTOR GMA-19-59-Y84 60 72011 TRACK BRACKET VP2 (33010540)
28a 64210 TIMING GEARBOX CAP (07100160-B) 61 62800 BENT ARM (050373)
28b 16233 TIMING SUPPORT GMA-18(ALPS) 62 62790 STRAIGHT ARM (050373)
29 61732 TIMING ASSY (01060234) 63 70155 C RAIL CH 3150 1P TA01 CTD
30 63223 DUST COVER TOP (01060325-A) 64 70170 FGCRTB1PTA02 -70170
31 10569 TAPTITE SCREW “P” M4 x 12 65a 72331 MAIN COVER AM808 GR SP
32 61792 TIMING HARNESS 350 ASSY (07100190) 65b 72332 MAIN COVER AM888 GR SP
33 40900 TRANSFORMER-10001-F_96VA-120V-25VAC 66a 65001 SIDE COVER LEFT VP2-3 GREY
34 10503 THRUSS SER HD SCREW “S” RoHS M4x 8 66b 65002 SIDE COVER RIGHT VP2-3 GREY
35 10504 THRUSS SER HD SCREW “S” RoHS M4x10 67 14818 NETWORK TRANSCEIVER NTR-1V1 AY
36 10505 THRS SER HD D.LK SCW S RoHS M4X10 68 61797 TIMING HARNESS ASSY VR10 (01100330)
69 61762 STRING HANDLE ASSY (01080340)
