4. Kit Contents
AM808 & AM888
AM800
1
(1) 1 x Drive unit
(2) 1 x Wall mount transmitter with battery and screws
(3) 2 x Transmitters and batteries
(4) 1 x Bent arm door attachment
(5) 1 x Straight arm door attachment
(6) 1 x Wall bracket TS01
(7) 1 x Door bracket Locator
(8) 1 x Door bracket
(9) 3 x Pin Snap SSP 8 ZNU 31080
(10) 2 x Hex Head screw M8x25
(11) 1 x Pin 0890
(12)
2 x Clevis Pin 0829
(13) 2 x Hex Serration flange nut M8
(14) 4 x Hex flange screw taptite ‘S’ M4 x 10
(15) 1 x Wired Safety Beam kit with brackets and screws
PLUS
(16) 2 x Track Bracket
(17) 1 x Pre-Assembled Single Piece C-Rail
NOTE: Chain/timing belt in one piece rail has been tensioned by
the factory. Do not adjust the tension of the chain/timing belt.
IMPORTANT NOTE: If modification to the track length required,
adjustment must be made only from power head end.
3
2
4
5
6
7
8
9
10
11
12
13
14
15
17
16
Fig.4.1
Fig.4.2
