35
Item
Part
Number
Description Qty. Item
Part
No.
Description Qty.
1 3014650 764 Series Control 1 17 1000269 Injector Cap with O-Ring 1
2 1244650 Valve Assembly w/o Flow Controls 1 18 1243511
0.33 Refill Ball & Cone Type Flow
Controller
1
3 1235340 Top Plate 1 19 Air Check Kit 1
4 1234170 Screw, Top Plate 12 1032416 3/8 –inch male
5 1235341 Valve Disc Spring, 255 Valve 1 1032417 1/4-inch NPT male threads
6 1236251 Cam 255 Logix Valve, Twin Tan 1 20 1033784 Tank Adapter 1
7 1236246 Cover, Grey 1 21 1010429 O-Ring, Tank 1
8 1000811 AC Adapter, North American 1 22 1232370 O-Ring, Riser 1
9 3019221 Motor/Optical Cable 1 23 1001404 O-Ring Group, Tank Adapter
10 1000226 Screen/Cap Assembly w/O-Ring 1 24 3016715 Assy, Sensor Cable Logix Twin 1
11 1031402 Locking Bar, English 25 3016775
Assy, Cable Extension 3 m (9.8 ft), Logix
Twin
1
12 1006093 Screw, Locking Bar 26 3020228 Assy, Cable Remote Start/Multi-Tank
13 Drain Control Assembly: 1 Lockout, 3 m (9.8 ft) 1
1000208 No. 6 (10 gpm; 3.8 Lpm) 27 1254886 Secondary Faceplate (blank) 1
1000209 No. 7 (1.3 gpm; 4.9 Lpm) 28 1032347 Assy, Adapter 1-inch Turbine 1
1000210 No. 8 (1.6 gpm; 6 Lpm) * 1000250 Valve Disc Kit 1
1000211 No. 9 (2 gpm; 7.6 Lpm) * 1040769 256 Bypass Valve Kit (Optional) 1
1000212 No. 10 (2.5 gpm; 9.5 Lpm) * 1267808 Valve Skirt 1
1000213 No. 12 (3.9 gpm; 14.8 Lpm) 29 1235446 Turbine Cable 1
1000214 No. 13 (4.5 gpm; 17 Lpm)
1000215 No. 14 (5.3 gpm; 20 Lpm)
14 1030502 Ball, Flow Restrictor 1
15 1040459 O-ring Group, Piping Boss
16 Injector Options: 1
1035730 “E” Injector, Yellow, 6-inch tank
1035731 “F” Injector, Peach, 7-inch tank
1035732 “G” Injector, Tan, 8-inch tank
1035733 “H” Injector, Lt Purple 9-inch tank
1035734 “J” Injector, Lt Blue 10-inch tank
1035735 “K” Injector, Pink 12-inch tank
1035736
“L” Injector, Orange, 13 & 14-inch
tank
* Not Shown on Drawing
