Autronica Autroprime Connecting

Connections to Other Loop Units
Connecting Loop Units, Interactive Fire Detection Systems, 116-P-CONNECTLOOPUNIT/DGB 2007-10-10,
Autronica Fire and Security AS
Page 13
3.5 AutroSense 75 Aspirating Smoke Detector
PRESS HERETRYKK HER
KNUS GLASSET
BREAK GLASS
AutroSense 75
(BW-75/AUT)
24 VDC
BN- 320
BRANNALARM
Tilpasningsenhet
FIRE ALARM
Interf ace uni t
Nr.
No.
Loop
Driver
Module
1 +
2 +
3 -
4 -
+ 24 V DC
+ 24 V DC
0 V
0 V
1 +
2 +
3 -
4 -
+ 24 V DC
+ 24 V DC
0 V
0 V
Loop
Loop
(to next detector)
24V DC out
+ -
24V DC in
+ -
- +
Loop in
Loop Connection
Connection to 24V DC
AutroSense 75
(BW-75/AUT)
