EMX-SKLUP User’s Manual
20 EMX-SKLUP User’s Manual
JSPI1
SPI connector
4 x 2 header, pitch 2.00mm
JEC_SPI
EC Debug
5 x 2 header, pitch 2.00mm
COM1
Serial Port 1 connector
5 x 2 header, pitch 2.00mm
COM2
Serial Port 2 connector
5 x 2 header, pitch 2.00mm
COM3
Serial Port 3 connector
5 x 2 header, pitch 2.00mm
COM4
Serial Port 4 connector
5 x 2 header, pitch 2.00mm
COM5
Serial Port 5 connector
5 x 2 header, pitch 2.00mm
COM6
Serial Port 6 connector
5 x 2 header, pitch 2.00mm
DIO1
General purpose I/O connector
10 x 2 header, pitch 2.00mm
SPK1
Speaker connector
4 x 1 wafer, pitch 2.00mm
LVDS1
LVDS Connector
20 x 2 wafer, pitch 1.25mm
USB1/2
USB connector 1/2
USB3/4
USB connector 3/4
5 x 2 header, pitch 2.54mm
SPDIF1
Sony/Philips Digital Interface
3 x 1 header, pitch 2.54mm
LAN1/2
RJ-45 Ethernet 1/2
PCIE1
PCIe connector
LED1
LED indicator connector 1
4 x 1 header, pitch 2.00mm
LED2
LED indicator connector 2
4 x 1 header, pitch 2.00mm
BT1
Battery connector
2 x 1 wafer, pitch 1.25mm
M2KA1
M.2 2230 Type A Slot
M2KB1
M.2 3042/2242/2260/2280 Type B Slot
DP1/2
DP connector 1/2
EDP1
eDP_Panel connector
10 x 2 wafer, pitch 1.25mm
JRS485_1/2
Serial Port 1/2 RS485/422 Mode
connector
3 x 2 header, pitch 2.00mm
JLPC
LPC connector
5 x 2 header, pitch 2.00mm
DCIN1
DC Power-in connector
PWR1
Power connector
2 x 2 wafer, pitch 4.20mm
SATA1/2
Serial ATA connector 1/2
SPWR1/2
SATA Power connector 1/2
4 x 1 wafer, pitch 2.54mm
I2C1
I2C connector
5 x 1 header, pitch 2.00mm
HDMI1
HDMI connector
LOUT1
Line-out audio jack
MIC1
Mic-in audio jack
DMIC1
Mic-in connector
5 x 1 header, pitch 2.54mm
SD1
SD card slot
