1.5 System Specifications
System
CPU
Onboard 6th Gen Intel® Core™ SoC i7/i5/i3 & Celeron®BGA Processor
BIOS
AMI uEFI BIOS, 128Mbit SPI Flash ROM
I/O Chip
EC IT8528E
System Memory
Two 260-pin DDR4 2133 MHz SO-DIMM socket, supports up to 32GB Max (non ECC
only)
Watchdog Timer
H/W Reset, 1sec. – 65535sec./min.1sec. or 1min. step
EEPROM
AMI uEFI BIOS, 128Mbit SPI Flash ROM
H/W Status
Monitor
CPU temperature monitoring
Voltages monitoring
CPU fan speed control
Expansion
1 x M.2 Type B 3042/2242/2260/2280 (with 2 x PCI-e x 1 (default) or 1 x PCI-e x 2
(By OEM BIOS ME SET), USB 2.0, USB3.0, SATA Signal) with 1 x SIM card slot,
support WWAN+GNSS or SSD with 1 x SIM card slot, support WWAN+GNSS or
SSD.
1 x M.2 Type A 2230 support WiFi module, 1 x PCI-e x 1, USB 2.0 Signal)
1 x SD card slot support SDXC/ SDHC 3.0 Card
1 x PCI-e x 1
S3/S4
Yes (S0/S3/S4/S5)
I/O
USB
4 x USB 3.0, 4 x USB 2.0
GPIO
16-bits GPIO
Display
Chipset
Intel® Processor Graphics
Resolution
1 x HDMI 1.4b: 3840 x 2160 @ 30 Hz, 2560 x 1600@ 30 Hz
2 x DP: DisplayPort 1.2a : 4096x2160 @ 60Hz (1 x HDMI/DP, 1 x DP++)
2CH 18/24bits LVDS 1920 x 1080 (Chrontel. CH7511B eDP to LVDS Converter)
Co-lay eDP 1.3: 4096x2160 BOM optional
Multiple Display
Triple Display
Display
1 x DP++, 1 x HDMI/DP, 1 x HDMI
LCD Interface
Dual channel 18/24-bits LVDS (Chrontel CH7511B eDP to LVDS) or eDP (optional)
Audio
AC97 Codec
Realtek ALC892 HD Audio Decoding Controller
Audio Amp
TI TPA3113D2PWP Stereo Class-D 6W x 2
Ethernet
LAN Chip
1 x Intel® I219LM Gigabit Ethernet PHY
