1 x Intel® I211AT PCI-e Gigabit Ethernet
Ethernet
Interface
Gigabit Ethernet
Internal I/O Connectors
Fan
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
System 1 I2C
1 x 1 x 5 pin, pitch 2.00mm, +3.3S Level
Buzzer
Onboard
CMOS Battery
1 x horizontal type battery connector (Battery cable 170mm length)
Power ON
1 x 2 x 5 pin, pitch 2.54mm connector for front panel 1
1 x 2 x 5 pin, pitch 2.54mm connector for front panel 2
Audio
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
External I/O
Connector
Storage:
1 x M.2 Type B 3042/2242/2260/2280 (with 2 x PCI-e x 1 (default) or 1 x PCI-e x 2
(By OEM BIOS ME SET), USB 2.0, USB3.0, SATA Signal) with 1 x SIM card slot,
support WWAN+GNSS or SSD.
1 x M.2 Type A 2230 support WiFi module, 1 x PCI-e x 1, USB 2.0 Signal)
- 2 x SATA III
- 2 x SATA power connectors
COM:
COM 1 & COM2
-COM 1 & COM2 support RS232/422/485 connector, with / +5V & +12V Supported
and RS422/485 by BIOS setting
2 x 2 x 5 pin, pitch 2.00mm connector for COM1: support RS-232 connector, Pin 9
with / +5V & +12V Supported
2 x 2 x 3 pin, pitch 2.00mm connector for COM1: support RS422/485 connector, Pin
5 with / +5V Supported
COM3~6:
- 4 x 2 x 5 pin, pitch 2.00mm connector for COM2~6: support RS-232 connector, Pin
9 with / +5V & +12V Supported
2 x 2 x 5 pin, pitch 2.54mm connector for 4 USB 2.0
1 x 2 x 10 pin, pitch 2.00mm connector for GPIO: 16 bits & +3.3S Level SMBus
1 x 2 x 4 pin, pitch 2.00mm connector for BIOS SPI
1 x 2 x 5 pin, pitch 2.00mm connector for EC SPI
1 x 2 x 5 pin, pitch 2.0mm connector for LPC
1 x horizontal type battery connector (Battery cable 170mm length)
1 x 2 x 5 pin, pitch 2.54mm connector for front panel 1
1 x 2 x 5 pin, pitch 2.54mm connector for front panel 2
1 x 2 x 20 pin, pitch 1.25mm connector for LVDS (must be using WF40H6-7GAA178
connector)
1 x 2 x 10 pin, pitch 1.25mm connector for eDP
