User’s Manual
EMX-SKLUP User’s Manual
13
1 x 1 x 5 pin, pitch 2.00mm Wafer connector for LCD inverter backlight connector
(5V/12V)
1 x 1 x 3 pin, pitch 2.54mm connector LCD backlight brightness adjustment
(PWM/DC)
1 x 2 x 5 pin, pitch 2.54mm connector for front Audio
1 x 3 pin, pitch 2.54mm connector for S/PDIF
1 x 4 pin, pitch wafer 2.00mm connector for 6W x 2 Speaker
1 x 3 pin, pitch 2.00mm connector for CMOS clear
1 x 1 x 4 pin, pitch 2.54mm CPU fan connector with smart fan function supported
2 x 1 x 4 pin, pitch 2.00mm connector for LAN Activity Indicator LED
1 x 1 x 5 pin, pitch 2.54mm for Digital MIC in
1 x 2 x 2 pin, pitch 4.20mm connector for power input connector
1 x 1 x 3 pin, pitch 2.54mm connector for AT/ATX mode Fanless Operating
Rear I/O Connectors
USB
4 x USB3.0
LAN
1 x Intel® I219LM Gigabit Ethernet PHY
1 x Intel® I211AT PCI-e Gigabit Ethernet
Display
1 x DP++, 1 x HDMI/DP
LED
2 x 1 x 4 pin, pitch 2.00mm connector for LAN Activity Indicator LED
Rear Side
External I/O
Connector
2 x RJ-45
4 x USB 3.0
1 x HDMI/DP
1 x HDMI
1 x DP++
1 x Mic-In and 1 x Line-out
1 x DC Jack lockable connector type
Mechanical & Environmental
Power
Requirement
DC in +12V~24V
ACPI
Single power ATX Support S0, S3, S4, S5
ACPI 5.0 Compliant
Power Type
AT / ATX mode Switchable Through Jumper
Operating Temp.
0 ~ 60°C (32~140°F)
Storage Temp.
-40 ~ +75°C
Operating
Humidity
0% ~ 90% relative humidity, non-condensing
Size (L x W)
6.7" x 6.7" (170mm x 170mm)
Weight
0.40 kg
