with slow devices may require more than 1 stop
bit.
Flow Control
None[Default]
Hardware RTS/CTS
Flow control can prevent data loss from buffer
overflow. When sending data, if the receiving
buffers are full, a ‘stop’ signal can be sent to
stop the data flow. Once the buffers are empty,
a ‘start’ signal can be sent to re-start the flow.
Hardware flow control uses two wires to send
start/stop signals.
VT-UTF8 Combo Key
Support
Disabled
Enabled[Default]
Enable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals.
Recorder Mode
Disabled[Default]
Enabled
With this mode enabled only text will be sent.
This is to capture Terminal data.
Resolution 100x31
Disabled[Default]
Enabled
Enables or disables extended terminal
resolution.
Legacy OS Redirection
Resolution
80x24[Default]
80x25
On Legacy OS, the Number of Rows and
Columns supported redirection.
Putty KeyPad
VT100[Default]
LINUX
XTERMR6
SCO
ESCN
VT400
Select FunctionKey and KeyPad on Putty.
Redirection After BIOS
POST
Always Enable[Default]
Boot Loader
When Bootloader is selected, then Legacy
Console Redirection is disabled before booting
to legacy OS. When Always Enabled is
selected, then Legacy Console Redirection is
enabled for legacy OS. Default setting for this
option is set to Always Enable.
